0.4 Inch Super Bright Red 7 Segment LED Display Triple Digit Common Anode
Product Description:
Character height: 0.4"( 10.16mm)
Outer dimensions: 30.1*16*7MM
Polarity: Common cathode
Yellow Epoxy black surface
Super Bright Red
Emitting colours: red, blue, green, white, amber, orange and yellow
Absolute Maximum Ratings(Ta=25ºC)
| Parameter | Symbol | Ratings | Unit |
| Forward Current(per dice) | Ipm | 20 | mA |
| Reverse Voltage(per dice) | Vr | 5 | V |
| Power Dissipation(per dice) | Pm | 80 | mW |
| Operating Temperature Range | Topr | -40~+85 | ºC |
| Storage Temperature Range | Tstg | -40~+85 | ºC |
| Solder Temperature(3 sec) | Th | 260 | ºC |
Code:Super Bright Red -R
| Parameter | Symbol | Condition | Min | Typ | Max | Unit |
| Forward Voltage | Vf | If=10mA | 1.8 |
| 2.2 | V |
| Reverse Voltage | Vr | Ir=10uA | 5 |
|
| V |
| Luminous Intensity | Iv | If=10mA | 50 |
| 60 | mcd |
| Spectrum With Of Half Value | △λ | If=10mA |
| 20 |
| nm |
| Wavelength | Dλ | If=10mA | 630 |
| 635 | nm |
Product Feature:
Forward voltage (high luminous intensity output)
Low power consumption
Extremely low current
Luminous evenly distributed on each segment
Industrial standard size
Provides excellent reliability in bright ambient light
Stable performance
Long lifetime
Meet RoHS/REACH compliant
Applications:
Audio equipments or instrument panels
Home electronic appliances
Numeric displays
Multimedia products
General use for digital indicators,temperature indiators, humidity indicators,process indicators,and so on
